PAOI-8041
PAOI-8041
Features :
- Support Intel® 8th Gen Coffee Lake-S processor in LGA1151
- Delivers up to 32GB maximum DDR4 2400 MT/s non-ECC SO-DIMM on two sockets
- High speed dual Gigabit Ethernet based on PCI express x 1, high bandwidth I/O interface
- Support 2x PCIe x16 slots (select 1x PCIe x16 or 2x PCIe x8 signal) and 2 PCI slots
Specification
| CPU | Intel® 8th Gen Coffee Lake-S processor in LGA1151 |
|---|---|
| Memory | Supports up to 32GB DDR4-2400MT/s SDRAM on two 260-pin non-ECC SO-DIMM sockets |
| Storage | -2x SATAIII ports -1x mSATA socket |
| I/O interface | -4x USB3.2 Gen1, 2x USB3.2 Gen2 -2x Gigabit Ethernet -2x mini DP up to 4096x2304 |
| Power Input | DC 12V ~ 36V with 3-pin Terminal Block Connector |
| Dimension | 230(W) x 231(D) x 150(H)mm |
| Weight | 5.8kg |
| Operating Temperature | 0 ~ 40 °C |
