MPI-815H

150W 1U ATX power supply with active PFC

Features :

Specification

Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
6A@115V, 3A@230V
Efficiency
> 75%
Holdup Time
16 ms at full load
Over Voltage Protection
+5V: 5.7 ~ 6.5V; +3.3V: 3.9 ~ 4.3V; +12V: 13.6 ~ 15
Over Power/ Load Protection
Output power over 110% ~ 150%
MTBF
>130,000 hrs
EMI & Safety Approval
UL
Temperature/ Humidity
Operating: 0oC ~ 40oC, 20% ~ 90%RH
Storage: -20oC ~ 60oC, 5% ~ 95%RH
Dimension (WxDxH)
198 x 93 x 40.5 mm; 7.8” x 3.66” x 1.6”
Ordering Guide
MPI-815H
150W fanless, 1U, ATX power supply
