GADIWA-N2480
480W Fan-less PS/2 Redundant DC-DC PSU, 19.2V~28.8VDC Input, ATX Output
Features :
- 480W DC-DC PS/2 mini-redundant suitable for embedded system
- 19.2V~28.8V wide-input, plug into ATX connector fit automotive and boat
- Compact and fan-less design fulfill mission-critical application
- LED alarm is easy for installation and maintenance
- MCU design help to monitor system status, temperature and performance
Description
GADIWA-N2480 480W DC-DC PS/2 mini redundant is an innovation stage to Portwell. It’s not only a design of fan-less but also with 3+1 modules in PS/2 size. GADIWA-N2480 provides MCU and LED alarm design to help you monitor system status and installation; it also provides connector cus tomization to meet any critical application.
GADIWA-N2480 is made & tested by automatic production line; therefore, can provide high quality and performance.
Specification
|
Input Voltage |
17.6A ~ 23.5A |
|
Input Current |
120Watts / 160 Watts Peak |
|
Efficiency |
85% |
|
Over Voltage Protection |
3.3V@3.9V; 5V@6.1V; 12V@13.8V |
|
Temperature/
Humidity |
Operating: 0 ~ 45°C, 20 ~ 90%RH Storage:-20 ~ 60°C, 5 ~ 95%RH |
|
Dimension (WxDxH) |
150 x 150 x 86 mm |
|
Ordering Guide |
|
|
GADIWA-N2480 480W Fan-less PS/2 Redundant DC-DC PSU, 19.2V~28.8VDC Input, ATX Output |
|
