| CPU | Intel Core i5-1245U |
| RAM | 2x SO-DIMM DDR4 3200MHz,Max 64GB |
| System Parameters | Storage | Supports M.2 NVME SSD |
| Network Port | 2 x Realtek RTL8111H/8111G 1000M ETH |
| Audio | 1 x MIC in, 1 x Line out |
| Display | HDMI, VGA, LVDS |
| I/O Interfaces | USB | 4 x USB 3.0 |
| GPIO | 1 x 8 channel GPIO(Optional) |
| Serial Port | 2 x COM (6 COM optional) |
| Display | 15” TFT LCD with LED Backlight |
| Resolution | 1024x768 with Aspect Ratio 4:3 |
| LED Screen | Viewing Angle Range | 85/85/85/85 (H/V) |
| Brightness | 300cd/m2 |
| Contrast | 800:1 |
| Maximum Color | 16M |
| Touch type | 10 points projected capacitive touch |
| Click life | 120 grams of strength, 1 million times |
| Touchscreen | Response time | <10ms |
| Transmittance | above 85% |
| High Temperature Test | 85℃/1000hrs |
| Constant temp and Humidity test | 85℃/90%RH/1000hrs |
| Panel Cabinet | Aluminium alloy frame |
| Installation method | Panel is embedded, can be installed with bracket by VESA |
| Mechanism Parameters | Power input | 230V AC ~ 12V DC External power adapter |
| Overall Dimensions | 378mm x 297mm x 57mm |
| Power | 40W desktop power adapter |
| Weight | 4 kg approx |
| Operating temperature | Designed to comply -10～60℃ |
| Storage Temperature | Designed to comply -20～70℃ |
| Environmental Parameters | Relative Humidity | 10～95%@40℃（non-condensing） |
| Shock | Complying running 10G peak acceleration (11ms interval) |
| Vibration | Complying random vibration 5 ～ 500Hz, 1Grms |
| Front Panel Protection | IP65 standard |
