AREMO-4197
19″ 4U industrial rack-mount chassis
Features :
- Two USB ports on the front panel
- 5.25” x3 + 3.5” x1 drive bays for RAID 0, 1, 5 & CD-ROM
- Traditional rack-mount handles
- PS/2 or Mini-redundant power supply installable
Description
The AREMO-4197 and AREMO-4197-MX is 19”4U Rack-mount chassis and designed for PICMG SBC/SHB and ATX form factor with stylish front panel design, up to 14-slot expansion for PICMG backplane. AREMO- 4197 series can support PS/2 PSU, two USB interface on front panel and build with replaceable air filter. AREMO-4197 series is suitable in several vertical markets, like Factory and Server applications.
Specification
|
TYPE |
4U |
|
MODEL |
AREMO-4197 AREMO-4197-MX |
|
SLOT |
14 ATX |
|
ORDERING GUIDE |
AREMO-4197 AREMO-4197/B AREMO-4197-MX AREMO-4197-MX/B |
|
BackPlane |
|||||||
|
BP MODEL |
PBPE-14AD64 |
PBPE-13A8 |
PBPE-13A4 |
PBPE-12AA64 |
PBPE-12A9 |
PBPE-12P4 |
PBPE-11A3 |
|
PICMG |
1.3 |
1.3 |
1.3 |
1.3 |
1.3 |
1.3 |
1.3 |
|
PCIe |
2 |
4 |
8 |
1 |
2 |
8 |
8 |
|
PCI/PCI-X |
3/8 |
8/0 |
4/0 |
2/8 |
9/0 |
4/0 |
3/0 |
|
Ordering Guide |
|
|
AREMO-4197 |
19” 4U rack-mount chassis for PICMG backplane |
|
AREMO-4197/B |
19” 4U black rack-mount chassis for PICMG backplane |
|
AREMO-4197-MX |
19” 4U rack-mount chassis for ATX M/B |
|
AREMO-4197-MX/B |
19” 4U black rack-mount chassis for ATX M/B |
