PEAI-9910

Features :

Description

The PEAI-9910 builds on Intel desktop R680E chipset and takes advantages of 12th/13th Generation Intel® Core™ i3/i5/i7/i9 processors technologies that can support dual DDR5 memory. Support two 5 Gigabit Ethernet ports, one M.2 M Key socket, one PCIe Gen5 x16 slot and one PCIe Gen4 x4 slot. The PEAI- 9910 is an ideal platform with rich I/O and high resolution for POS, kiosk, digital signage and factory automation applications.

General

CPU
Intel® 12th /13th Generation Core™ i3/i5/i7/i9 processors family in LGA1700 package
Memory
Supports up to 64GB DDR5 4800 SDRAM on two SO-DIMM sockets
Supports ECC
M/B
Proprietary ROBO-9910G2AR-A
Chipset
Intel® R680E
BIOS
AMI uEFI BIOS
Storage
Supports 2x 2.5inch SSD or 2x 3.5inch HDD Draw Box
Supports RAID 0, 1, 5, 10
Watchdog Timer
Programmable watchdog timer, time out period from 0.5 sec to 254.5 secs.
Hardware Monitoring
System monitor(Voltage Speed and Temperature)
Expansion Interface
1x PCIe x16 Gen5 slot
1x PCIe x4 Gen4 slot
Supports 1x M.2 Type M 2280 with PCIex4 signal
Power Input
AC to DC
AC 100~240V
Power Supply
650W

Mechanical

Dimension
415mm(L)*182mm(W)*280mm(H)
Weight
10 Kg

Environment

Operating temperature
0°C ~ 40°C
Storage Temperature
-20°C ~ 80°C

External I/O

Audio
Line-Out & Mic-In
Display
1x HDMI® 2.0, supports up to 4096 x 2160 @ 60 Hz
1x DP 1.2, supports up to 4096 x 2160 @ 60 Hz
Ethernet
2x 5 Gigabit Ethernet ports (Marvell AQC114CS)
Serial Port
1x RS-232/422/485 port
USB
-2x USB 3.2(Gen2) ports
-4x USB 3.2(Gen1) ports
GPIO
1x 8-bit Digital I/O port
